MIL-DTL-85069D
3.3.2 Discontinuities. There shall be no laps or folds, seams or discontinuities, or other
interruption in grain flow.
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are
classified as conformance inspection (see 4.2).
4.2 Conformance inspection.
4.2.1 Sampling for examination. Test samples shall be selected at random in accordance
with ASQ Z1.4, with the sampling level as specified in table I. The acceptance quality limit
(AQL) shall be as specified in the contract or purchasing order (see 6.2). Identical sample items
may be used for any of the tests, provided that selection of random samples is maintained and
known characteristics of the samples are not used to influence the integrity of the test results.
TABLE I. Conformance examination.
ASQ Z1.4
Reference
Test
sampling
paragraph
inspection level
Inspection lot
4.2.2
-
Examination
4.3.1
II
Material certification
4.3.3
-
Grip length break
4.3.4
II
4.2.2 Inspection lot. A lot shall consist of sleeves or grommets made from the same lot
of material and fabricated as a single continuous production run in which the forming machine
set-up remains unchanged except for head configuration. A lot shall be restricted to one sleeve
or grommet diameter or material thickness. A lot of material shall be defined as the quantity of
sheet or strip steel made from a single heat. It shall be controlled and shipped with appropriate
mill certification. In addition, the manufacturer shall maintain a record of inspections by lot
number for a period of three years.
4.2.3 Certified test report. The manufacturer shall furnish certification that the product
conforms to this specification. The record shall state that the product meets all the requirements
of this specification.
4.3 Examination and tests.
4.3.1 Examination. Each of the sample sleeves or grommets selected for examination
shall be examined for conformance to the requirements for dimensions, workmanship,
identification, and to all requirements not covered by the tests. Samples failing to meet
examination requirements shall result in rejection of the lot.
4
