INCH-POUND
MIL-DTL-3390H
11 February 2011
SUPERSEDING
MIL-DTL-3390G
19 November 2007
DETAIL SPECIFICATION
RINGS, DEE
This specification is approved for use by all Departments and Agencies of the
Department of Defense.
1. SCOPE
1.1 Scope. This specification covers dee rings for use on various equipage items
(see 6.1).
1.2 Classification. The dee rings will be of the configurations shown by letter
designations on drawings 4-1-454 or 4-1-455, as specified (see 6.2) and will be of the following
classes and sizes for the configuration shown. Configuration X will be style 1 (without roller) or
style 2 (with roller), as specified (see 6.2).
Class 1 -
Brass
Class 2 -
Steel wire
Class 3 -
Malleable iron
Class 4 -
Nickel-silver alloy
Class 5 -
Molding plastic (nylon) rigid
1.2.2 Configurations. The configurations of the dee rings are shown by letter
designations on drawings 4-1-454 and 4-1-455, as specified (see 6.2).
1.2.3 Sizes. Configurations A, D, K, L, W, and X are available in various sizes as shown
on drawing 4-1-454, as specified (see 6.2).
Comments, suggestions, or questions on this document should be addressed to Defense
Logistics Agency Aviation VEB, 8000 Jefferson Davis Highway, Richmond, VA 23297-5616,
or e-mailed to STDZNMGT@dla.mil. Since contact information can change, you may want to
verify the currency of this address information using the ASSIST database at
https://assist.daps.dla.mil/.
AMSC N/A
FSC 5365
